Chore-Time C2 PLUS User Manual

MODEL C2® PLUS & MODEL G™ PLUS with Proximity Sensor Feeding System Parts List
MF2495A
57
*Actuator Switch, Chore-Time part number 7114, is no longer available. When replacing, use 7114 Switch
Replacement Kit Part Number 46678.
Item Description MODEL
C2 PLUS
Standard
Part No.
40945
MODEL
C2 PLUS
Shallow
Part No.
42013
MODEL
G PLUS
Standard
Part No.
40946
MODEL
G PLUS
Shallow
Part No.
42029
1 Danger/Product Identification Decal 2529-658 2529-248 2529-657 2529-694
2 Danger Decal 2527-9 2527-9 2527-9 2527-9
3 Back Cover 25047 25047 25047 25047
4 Front Panel 25046 25046 25046 25046
5 Tube Support 41364 41364 41364 41364
6 Paddle Retainer 25045 25045 25045 25045
7 Pivot Bracket 25048 25048 25048 25048
8 Spring 6972 6972 6972 6972
9 #10-32 Lock Nut 6963 6963 6963 6963
10 Gasket 6968-1 6968-1 6968-1 6968-1
11 Switch Box Cover 6776 6776 6776 6776
12 Gasket 6777 6777 6777 6777
13 Actuator Pin 8757 8757 8757 8757
14 Support Cone Assembly 40947 37371 40947 37371
15 Tube Retainer 14756 14756 14756 14756
16 Cord Assembly 4999-49 4999-49 4999-49 4999-49
17 1/2” Liquid Tight Connector 24685 24685 24685 24685
18 Machined Switch Box 34842 34842 34842 34842
19 Switch Bracket 46122 46122 46122 46122
20 Switch Insulation 1907-5 1907-5 1907-5 1907-5
21* Actuator Switch 46091 46091 46091 46091
22 Cut Sleeve 43110 43110 43110 43110
23 Mylar Assembly 25318 25318 25318 25318
24 Switch Paddle 46123 46123 46123 46123
25 Feeder Pan 41501 41500 41501 41500
26 Feeder Grill 39567 39567 38599 38599
27 Adjustment Cone 38604 41504 38604 41504
