Installation for Brood-Grow Cage Systems Only ULTRAFLO
®
Cage Feeding Systems for Brood Grow & Layer Installations
10
MC656P
Trough Installation
Trough Support
Note: Refer to the appropriate section for your
cage style.
All Brood-Grow Cage Styles when Step Rail
Brackets are used: Install a Trough Support on each
Cage Floor Support--on the bottom tier (only). (See
Figure 6.)
D.B.S. & Curtain-Backed Brood-Grow Systems ONLY (w/o Step Rail Brackets): Install a
Trough Support on each Cage Floor Support --on all tiers (See Figure 7.).
Do not install Trough Supports on Intermediate Legs.
2 + 2 Brood-Grow Systems ONLY (w/o Step Rail Brackets): Install a Trough Support on each
Cage Floor Support--on tiers #2 and #4 only (See Figure 7.).
Do not install Trough Supports on Intermediate Legs.
Stacked Brood-Grow Systems ONLY (w/o Step Rail Brackets): Install a Trough Support
bottom on tier only (See Figure 7.).
MC656-15 8/95
1
2
Figure 6.
Key Description
1 Trough Support
2 Floor Support
Key Description
1 Trough Support
2 Floor Support
Figure 7.
