HIPOT Tester 19051/19052/19053/19054 Quick Start Guide
Figure 2-3
6. The dangerous area under test mode
It is very danger to touch high voltage area under operation status.
Such as touch DUT, test cable, probe and output terminal.
CAUTION
When the main unit is under test status, please don’t
touch alligator clipper on test cable. Because the
insulation of plastic layer is not enough, touch it may
cause hazard. As figure 2-4.
Figure 2-4
Please don’t touch here when
high voltage output
<<< Warning ! When the output terminal is cut off. >>>
7. Test complete confirmation
You may touch DUT, high voltage test cable or output terminal etc high
voltage areas under modifying circuit or others test requested
conditions. Please confirm the following at the first.
Power switch is turned off.
As the insulation resistance test unit, DUT may full of high voltage when
test is completed. In the meantime, you need to pay attention to obey
descriptions of item 8 and 9 of this chapter. As the described
10
