37
OUT9, ... , OUT10 Alarms
Function Configurable (default: alarms)
Relay Type 5A NO Contact, 250V/30Vdc COSw =1
COMMUNICATIONS
PORT 1 (present)
Function Local serial communication
Protocol ModBus RTU
Baudrate Settable to 1,2...57.6kbits/s, (default 19.2 kbit/s)
Address Node Settable by rotary switch
Type
RS485
1500V isolation, double connector RJ10 telephone type 4-4
PORT 2 (Fieldbus Option)
Function Fieldbus serial communication
Protocol
ModBus RTU, type RS485, baudrate 1,2...57.6 kbit/s
CANOpen 10K….1Mbit/s
DeviceNet 125K...0.5Mbit/s
Profibus DP 9.6K...12 Mbit/s
Ethernet Modbus TCP, Ethernet IP 10/100Mbps
EtherCAT, ProfiNET 100Mbps
POWER (SOLID STATE POWER UNITS, 4 UNITS)
Rated Voltage 480VAC
Work Voltage Range 24...530 Vac
Non- repetitive Voltage 1200Vp
Zero Switching Voltage <20V
Rated Frequency 50/60Hz self-setting
Rated Current AC51 30KW 60KW 80KW
4 x 16A 4 x 30A 4 x 40A
Non- Repetitive Overcurrent (t=20 msec)
400A 600A 1150A
I
2
t For Fusion (t=1...10 msec) 645A’s 1010A’s 6600A’s
Critical Dv/dt with output Deactivated 1000V/usec
Rated Isolation Voltage 4000V
FUNCTIONS
Safety
Detects short circuit or open probe circuit, probe, power supply failure, LBA
alarm, HB alarm
Selection ˚C/˚F Configurable
Linear scale range -1999 ... 9999
Control Actions
4 control loops:
Double action (heat/cool) PID, on-off
Self-tuning at power-up, Continuous Autotuning, One-shot Autotuning
pb-dt-it 0,0 ... 999,9 % - 0,00 ... 99,99 min - 0,00 ... 99,99 min
Action - Control Outputs heat/cool - ON/OFF, PWM, GTT
Heat/Cool Max. Power Limitation 0,0 ... 100,0%
Cycle Time – Softstart
0 ... 200 s - 0,0 ... 500,0 min
Softstart at phase slicing
Fault Power Setting -100,0 ... 100,0%
Shut-Down Function Maintains sampling of process variable PV; when active, disables control
