CHTC HT45 - Instrument Panel Indicators

CONTROLS
12
Table 1: Instrument Panel Face
Table 1: Instrument Panel Face
Number Item
1
Brake Pad Wear Indicator
This light appears when the brake pad is worn and thin.
2
Battery Warning Indicator
The light appears when battery failure occurs and needs
to be replaced.
3
Check Transmission
When transmission electronic control unit detects errors
on the transmission, this light will appear.
4
ABS Fault Indicator
When an error occurs with ABS system, this light will
appear.
5
Engine Coolant Hot
When engine coolant temperature is high, this light will
appear.
6
Park Brake Applied
When the vehicle has stopped and the driver applied
parking brake, this light will appear.
7
Brake System Warning
When electronic system found air pressure is under 6
bars, this light will appear.
Number
Ite
8
Seatbelt Warning
If driver is not wearing seat belt, this light will appear.
9
Engine Oil Pressure
When the electronic system find engine oil pressure
does not match calibration data, this light will appear.
10
Engine Fault Stop
Engine is not operating properly. Engine may derate,
with reduced power or speed if problem is detected.
Action: bring vehicle to safe stop as quickly as possible
and have vehicle serviced before resuming. Note: if
engine shuts down and vehicle is still on the road it may
be possible to restart for brief period (approximately 30
seconds) after turning the ignition off to allow vehicle to
be moved to safe location.
11
Engine Fault Warning
Engine is not operating properly. Engine may derated,
with reduced power or speed if problem is detected.
Action: seek a service facility to address the registered
fault code at the earliest opportunity.
12
Engine Malfunction Indicator Lamp
The light indicates that the electronic system has
detected malfunction related to emission control
system and the after-treatment system should be
diagnosed and serviced at your next available
opportunity.
