Table 1: Instrument Panel Face
Table 1: Instrument Panel Face
Number Item
19
Water in Fuel
Water has been sensed in fuel filter assembly. This can
cause the engine to run rough and be difficult to start.
Action: water must be drained from fuel filter assembly.
Have vehicle serviced as soon as possible.
20
Fog Lights
This light indicates that the fog lights are turned on.
21
Left Turn Indicator
This light indicates that the turn left signal is on.
22
Right Turn Indicator
This light indicates that the turn right signal is on.
23
Cruise Control
When the TFT screen is used for reverse monitor, this
button is used to turn on the Brightness Function.
24
High Beam
This light indicates that the high beam is on.
25
MPH Indicator
26
km/h Indicator
Number Item
Wait to start engine preheat. Do not start engine until
after light goes out.
14
High Exhaust System Temperature (HEST)
The light indicates that high exhaust temperatures may
exist due to after treatment regeneration. This is normal
and does not signify the need for any kind of vehicle
service or engine service. When this lamp is illuminated,
ensure that the exhaust pipe outlet is not directed at any
combustible surface or material
15
DPF Status Indicator
This light indicates that DPF regeneration is required.
16
Exhaust After Treatment Warning
This light indicates that the after treatment DPF
requires regeneration. This is accomplished by the
following:
1. If the vehicle is equipped with regeneration inhibit
switch, ensure that the switch is not in inhibit position.
2. Perform DPF regeneration by one of the following:
a. Change to a more challenging duty cycle such as
highway driving for at least 20 minutes.
17
Low DEF
This light indicates that the DEF level is low.
18
Low Fuel
When diesel fuel level is low, this light will appear.
