TFT Screen Indicator Symbols
Table 3: TFT Screen Indicator Symbols
Table 3: TFT Screen Indicator Symbols
Number Item
6
Disabled Service Requirement
7
Heater Working Indicator
8
ASR System Functional or Error Indicator
9
ECAS Warning Indicator
10 EACS Error Indicator
11 ECAS Kneeling Indicator
12 Body State Indicator
13 Fog Lamp Indicator
Letter Item
14 Retarder Functional Indicator
15
Transmission Gear Indicator
16
Cooling Water Level Warning Indicator
17
Air Filter Warning Indicator
18 Hydraulic Fan Warning Indicator
19 Transmission Oil Temperature Warning Indicator
20 Tag Axle Release Pressure Indicator
21 Kilometer/mileage Display
22 Emergency Door Indicator
23 Passenger Door Indicator
24 Engine Cabin Door Indicator
25 Time Display
26
Engine Temperature
27 Engine Lubrication System Pressure
28 Adblue Liquid Level Display
29 Accelerator Pedal Position Display
30 Current Fuel Consumption
31 Average Fuel Consumption
