Backrest Adjustment
Pull up the locking lever to release the backrest catch. The backrest is
brought into the desired position by simultaneously exerting or relieving
pressure. Release the locking lever to lock the backrest.
NOTE: It should not be possible to move the backrest into another
position after it has been locked.
Seat Heater ( OPTIONAL )
By operating the seat heater switch, the heating mats in the backrest
and seat cushion can be heated in two steps.
•
0 = Heater Off
•
1 = Heating step 1 ON
•
2 = Heating step 2 ON
Armrests
The armrests can be folded up if required.
Armrest Adjuster
The inclination of the armrests can be modified by turning the
adjustment knob. When turning the knob to the outside “+”, the front
part of the armrest will be tilted. When turning the knob to the inside “-”,
it will be lowered.
Seat Pan Angle Adjustment
Adjust the angle of the seat pan by pulling the left handle upwards. The
seat pan can be moved to the desired position by pressing or relieving
the seat to the front or to the rear.
NOTE: The adjustment range can be made between minus 6º and 10º.
Seat Depth Adjustment
Pull the right handle upwards to adjust the depth of the seat cushion.
Move the seat cushion backwards or forwards so the desired seating
position can be reached.
NOTE: Adjustment range of 2.3 in. (58 mm) is in six increments.
Fore/aft Adjustment
The forward/aft adjustment can be made by pulling the locking handle,
while simultaneously sliding the seat forwards or backwards to the
desired position.
WARNING
The seat must lock into place with an audible click when the lever
is released.
NOTE: The adjustment range can be made in ten steps of 0.78 in. (20
mm) each.
