105
The tables below list reader settings as well as symbology settings for the Long Range
Laser (LR) or Extra Long Range Laser (ELR) scan engine.
READER SETTINGS TABLE
LR/ELR Description Default
Aiming Duration Decide whether to have the aiming dot. When you press
the [SCAN] button, the scan engine will emit a red dot for
aiming. It will stay on until it times out or you press the
[SCAN] button again. Then, it will emit a scan beam.
0~9, in units of 1 second.
Enter 0 if aiming is not desired.
No aiming
Decode Time-out Set the maximum time for decoding to continue during a
scan attempt.
5~99, in units of 0.1 second.
3.0 sec.
Transmit AIM Code
ID
Decide whether to include AIM Code ID in the beginning of
data. Each AIM Code ID contains the three-character
string “]cm” –
] = Flag Character (ASCII 93)
c = Code Character (see below)
m = Modifier Character (see below)
Disable
AIM CODE ID – CODE CHARACTERS
Code Character Code Type
A Code 39
C Code 128
E UPC/EAN
F Codabar
G Code 93
H Code 11
I Interleaved 25
M MSI
S Discrete 25, IATA 2 of 5
X Code 39 Trioptic, Bookland EAN
Appendix III
