CipherLab 8000 Series User Manual

101
Appendix II
CCD/Laser Scan Engine
SYMBOLOGY SETTINGS TABLE
CCD/Laser Description Default
Codabar Enable
Select Start/Stop
Characters
If "Transmit Start/Stop Characters" is desired, select one
set:
 abcd / abcd
 abcd / tn*e
 ABCD / ABCD
 ABCD / TN*E
abcd/abcd
Transmit Start/Stop
Characters
Decide whether to include the start/stop characters in the
data being transmitted.
No
Code 128 Enable
GS1-128 Enable
Transmit Code ID
Decide whether to include Code ID (“]C1”) will be included
in the data being transmitted.
No
Field Separator Decide whether to replace the field separator. For
example, type the desired character “;” (semicolon) as the
new field separator.
No
Industrial 25 (= Discrete 25) Enable
Start/Stop Selection This decides the readability of all 2 of 5 symbology
variants. For example, flight tickets actually use an
Industrial 2 of 5 barcode but with Interleaved 2 of 5
start/stop pattern. In order to read this barcode, the
start/stop pattern selection parameter of Industrial 2 of 5
should set to "Interleaved 25".
Industrial 25
Verify Checksum Decide whether to verify the checksum. If the checksum is
incorrect, the barcode will not be accepted.
No
Transmit Checksum Decide whether to include the checksum in the data being
transmitted.
Yes
Select Length
 One or two fixed lengths
 Range
4~127
Interleaved 25 Enable
Start/Stop Selection Refer to Industrial 25. Interleaved
25
Verify Checksum Decide whether to verify the checksum. If the checksum is
incorrect, the barcode will not be accepted.
No
Transmit Checksum Decide whether to include the checksum in the data being
transmitted.
Yes
Select Length
 One or two fixed lengths
 Range
4~127
Matrix 25 Enable
Start/Stop Selection Refer to Industrial 25. Matrix 25

CipherLab 8000 Series Specifications

General

Humidity	5% to 95% non-condensing
Communication	Infrared
Barcode Scanner	Laser
Connectivity	Infrared
Storage Temperature	-20°C to 60°C
Keypad	21 keys (numeric / functional)
