CipherLab 8000 Series User Manual

115
Appendix IV 2D Scan Engine
SYMBOLOGY SETTINGS TABLE
The symbology settings for the LR/ELR scan engine are all supported on the 2D scan engine. In
addition, the 2D scan engine supports the following symbology settings:
2D Description Default
Code 11 Enable
Verify Checksum Decide whether to verify the checksum. If the checksum is
incorrect, the barcode will not be accepted.
 No verification
 One Check Digit
 Two Check Digits
No
Transmit Checksum Decide whether to include the checksum in the data being
transmitted.
 "Verify Checksum" must be enabled so that the
checksum can be left out (= "Transmit Checksum"
disabled).
No
Select Length
 Any Length
 One or two fixed lengths
 Range (1~55)
4~55
Postal Codes ---
US Postnet Enable
US Planet Enable
Transmit US Postal
Checksum
US Postnet or US Planet must be enabled first! Enable
UK Postal Enable
Transmit UK Postal
Checksum
UK Postal must be enabled first! Enable
Japan Postal Enable
Australian Postal Enable
Dutch Postal Enable
Composite Codes ---
Composite CC-C Enable
Composite CC-A/B Disable
Composite TLC-39 Disable
GS1 Code 128
Emulation Mode
Transmit data as if it was encoded in Code 128 barcodes.
 Transmit AIM Code Identifier must be enabled first!
Disable

CipherLab 8000 Series Specifications

General

Humidity	5% to 95% non-condensing
Communication	Infrared
Barcode Scanner	Laser
Connectivity	Infrared
Storage Temperature	-20°C to 60°C
Keypad	21 keys (numeric / functional)
