STREAM Wireless Studio User Guide
UPC Composite Mode UPC barcodes can be "linked" with a 2D barcode during
transmission as if they were one barcode.
UPC Never Linked
Transmit UPC barcodes regardless of whether a 2D
barcode is detected.
UPC Always Linked
Transmit UPC barcodes and the 2D portion. If the 2D
portion is not detected, the UPC barcode will not be
transmitted.
 CC-A/B or CC-C must be enabled!
Auto-discriminate UPC Composites
Transmit UPC barcodes as well as the 2D portion if
present.
UPC Always
Linked
2D Symbologies ---
PDF417 Enable
MicroPDF417 Disable
MicroPDF417 Code 128
Emulation
Transmit data from certain MicroPDF417 barcodes as if it
was encoded in Code 128 barcodes.
 Transmit AIM Code Identifier must be enabled first!
When applied, the MicroPDF417 barcodes are transmitted
with one of these prefixes:
The first codeword of MicroPDF417 is 903-907, 912,
914, 915:
The original Code ID "]L3" will be changed to "]C1".
The first codeword of MicroPDF417 is 908 or 909:
The original Code ID "]L4" will be changed to "]C2".
The first codeword of MicroPDF417 is 910 or 911:
The original Code ID "]L5" will be changed to "]C0".
Disable
Data Matrix Enable
Maxicode Enable
QR Code Enable
2D Symbologies - Macro PDF ---
Macro PDF is a special feature for concatenating multiple PDF barcodes into one file, known as
Macro PDF417 or Macro MicroPDF417.

CipherLab 8000 Series Specifications

General

Humidity	5% to 95% non-condensing
Communication	Infrared
Barcode Scanner	Laser
Connectivity	Infrared
Storage Temperature	-20°C to 60°C
Keypad	21 keys (numeric / functional)
