The tables below list reader settings as well as symbology settings for the 2D scan
engine.
READER SETTINGS TABLE
2D Description Default
Focus Mode Select the focus mode to control the working range:
Far Focus – optimized to read at its far position
Near Focus – optimized to read at its near position
Smart Focus –
toggles the focus position after every
frame
Far Focus
Decode Illumination Decide whether to flash illumination on every barcode
capture to aid decoding.
Turn On (Internal LED )
Turn Off
On
Aiming Pattern Decide whether to project the aiming pattern during
barcode capture.
Turn On
Turn Off
On
Decode Time-out Set the maximum time for decoding to continue during a
scan attempt.
5~99, in units of 0.1 second.
3.0 sec.
Transmit AIM Code
ID
Decide whether to include AIM Code ID in the beginning of
data. Each AIM Code ID contains the three-character
string “]cm” –
] = Flag Character (ASCII 93)
c = Code Character (see below)
m = Modifier Character (see below)
Disable
AIM CODE ID – CODE CHARACTERS
Code Character Code Type
A Code 39, Code 39 Full ASCII, Code 32
C Code 128, Coupon (Code 128 portion)
d Data Matrix
E UPC/EAN, Coupon (UPC portion)
e GS1 Databar Family
