68
FORGE Batch Application Generator User Guide
2.1 SELECT A MENU
Menu 1~10 are available. Select one to start with, usually "Menu 1".
Each Menu carries these group boxes: the [Properties], [Font Properties], [Color
Properties] (8600 only), [Data], a command name editing table, a checkbox to enable
the Edit Form Name button, and a Reset Current Menu button.
2.2 PROPERTIES
[Property] group box features the settings of Menu caption and Esc. The former
specifies the title of the menu while Esc configures the data collecting form or any other
menu to succeed the menu.
In the following content of this section, you will be walked through said settings one by
one.
2.2.1 MENU CAPTION
Select “Menu Caption” to be able to specify a title for the menu if necessary.
2.2.2 ESC
Select a form or menu to display when the [ESC] key is pressed to the menu. Options
available are:
Main Menu
Form 1 ~ 10
Menu 1 ~ 10
Note: Normally, the [ESC] key is used to return to a previous form or menu.
2.3 FONT PROPERTIES
Large font is only applicable to the double-byte languages such as Chinese, Japanese, etc.
For a menu, font size needs to be configured according to the font in use on the mobile
computer.
Refer to
Localization and 1.3 Font .
