196
End Programming Format
1560 Series Barcode Scanner User Guide
Field 3 Setting
1. Read the barcode below to divide field 3 by a specified terminating string.
elect
ield Separator
to Divide Field 3…
2. Read the “Hexadecimal Value” barcode on page 228 for the desired character string.
3. Read the “Validate” barcode to complete this setting.
4. Read the “Discard Separator” barcode if the field separator is not desired in the field.
*Include Separator
Discard Separator
If not dividing the field by a specific separator, you may divide it by a specified length.
1. Read the barcode below to divide field 3 by length.
ivide Field 3
by Length
2. Read the “Decimal Value” barcode on page 227 for the desired field length.
3. Read the “Validate” barcode on the same page to complete this setting.
