73
Update
Chapter 2
Selecting Output Interface
2.4.1 ACTIVATE KEYBOARD WEDGE & SELECT KEYBOARD TYPE
When Keyboard Wedge interface is activated, you will have to select a keyboard type to
complete this setting.
Activate 3656
Keyboard Wedge &
Select Keyboard
Type…
1) Read this barcode above to activate Keyboard Wedge and select a keyboard type.
2) Read the “
Decimal Value” barcode on page 227. Refer to the table below for the
number of desired keyboard type.
3) Read the “Validate” barcode on the same page to complete this setting.
Keyboard Wedge via 3656
By default, the keyboard type is set to PCAT (US). The following keyboard types are supported
when using 3656 with the keyboard wedge cable provided —
No. Keyboard Type No.
Keyboard Type
1 PCAT (US) 16 PS55 001-2
2 PCAT (French) 17 PS55 001-82
3 PCAT (German) 18 PS55 001-3
4 PCAT (Italian) 19 PS55 001-8A
5 PCAT (Swedish) 20 PS55 002-1, 003-1
6 PCAT (Norwegian) 21 PS55 002-81, 003-81
7 PCAT (UK) 22 PS55 002-2, 003-2
8 PCAT (Belgium) 23 PS55 002-82, 003-82
9 PCAT (Spanish) 24 PS55 002-3, 003-3
10 PCAT (Portuguese) 25 PS55 002-8A, 003-8A
11 PS55 A01-1 26 IBM 3477 Type 4 (Japanese)
12 PS55 A01-2 (Japanese) 27 PS2-30
13 PS55 A01-3 28 IBM 34XX/319X, Memorex Telex 122 Keys
14 PS55 001-1 29 User-defined table
15 PS55 001-81 30 PCAT (Turkish)
To Next Page
