This chapter will guide you through the features of the barcode scanner and how it can

function for you.

IN THIS CHAPTER

1.1 Battery..................................................................... 23

1.2 Memory.................................................................... 29

1.3 LED Indicator ............................................................ 32

1.4 Beeper ..................................................................... 34

1.5 Send “NR” to Host ..................................................... 38

1.6 Scan Modes .............................................................. 39

1.7 Scanning Timeout ...................................................... 44

1.8 Delay between Re-read............................................... 45

1.9 Read Redundancy for All Symblogies ............................ 46

1.10 Addon Security for UPC/EAN Barcodes ........................ 47

1.11 Auto-Sense Mode (1560 Only) ................................... 48

1.12 CCD Sensor Always Active (1560 Only) ....................... 50

1.13 Negative Barcodes ................................................... 50

1.14 Effective Decoding Area ............................................ 51

1.1 BATTERY

The scanner is powered by a rechargeable 3.7 V/800 mAh Li-ion battery, and it takes

approximately 5 hours to charge the battery to full (via 3656 from the power adaptor).

However, the charging time may vary by working condition. For intensive data collection,

you may need to purchase a spare battery for non-stop operation.

Note: See also “

Power Economy”, “CCD Sensor Always Active”, “Sniff Mode”, as well as

“Low Battery Alarm”.

1.1.1 TURN ON/OFF THE SCANNER

Turn on the scanner…

After installing the battery, pull down the trigger for about 2 seconds. The scanner will respond

with a long beep (high tone), then the LED will become solid red and go off quickly.

Turn off the scanner…

Remove the battery directly or let it turn off automatically in specific circumstances.

Chapter 1

UNDERSTANDING THE BARCODE SCANNER
