CipherLab RK25WO User Manual

188
RK25WO Mobile Computer
EXAMPLE
The followings are the examples of barcodes to be filtered by criteria:
Barcode
Details
Barcode 1
Symbology:
EAN13
Barcode data:
0001112223334
Length:
13
Barcode 2
Symbology:
EAN13
Barcode data:
4445556667778
Length:
13
Barcode 3
Symbology:
EAN13
Barcode data:
888999000
Length:
9A
Barcode 4
Symbology:
Code39
Barcode data:
5555222221111
Length:
13
If the criteria are set as:
1) “Barcode Input” is “All”:
Barcode 1 (EAN13), Barcode 2 (EAN13), Barcode 3 (EAN13),and Barcode 4 (Code39) all
match the criteria.
2) “Barcode Input” is “EAN13”:
Barcode 1 (EAN13), Barcode 2 (EAN13), and Barcode 3 (EAN13) meet the criteria.
3) “Barcode Input” is “EAN13”, and “String Length” is “9”:
Only Barcode 3 (EAN13; length= 9) matches the criteria.
4) “Barcode Input” is “EAN13”, and “String Length” is “10”:
None of the barcodes fulfils the criteria.
5) “Barcode Input” is “All”, and “String Length” is “13”:
Barcode 1 (EAN13; length= 13), Barcode 2 (EAN13; length= 13), and Barcode 4 (Code39;
length= 13) meet the criteria.
6) “Barcode Input” is “All”, and “Specific String” is “000”:
Barcode 1 (EAN13; 0001112223334) and Barcode 3 (EAN13; 888999000) meet the
criteria.
7) “Barcode Input” is “All”, and “Specific String” is “111”:
Barcode 1 (EAN13; 0001112223334) and Barcode 4 (Code39; 5555222221111) match
the criteria.
8) “Barcode Input” is “All”, “Specific String” is “111”, and “String Position” is “4”:
Only Barcode 1 (EAN13; 0001112223334) matches the criteria.
9) “Barcode Input” is “All”, “Specific String” is “111”, and “String Position” is “1”:
None of the barcodes fulfils the criteria.
