4�3�-DISPLAY
ThedevicehasabacklitLCDdisplayshowingalltheparameterslistedinTable 4.
Thedisplayisdividedintotwoareas(Figure 12):
Theconsumption dataareashowingconsumptionparameters�
Theinstantaneous dataareashowingthemaximumandminimuminstantaneous
 valuesbeingmeasuredorcalculatedbythedevice�
Figure 12: CVM-C5 display areas�
4�3�1� CONSUMPTION DATA AREA
Thedevicehas22di󰀨erentscreensintheconsumptiondataarea(Table 7)�
Table 7: Consumption data area screens�
Screen Units
TotalactiveenergygeneratedTari󰀨1
kWh
InductivereactiveenergygeneratedTari󰀨1
kvar
L
h
CapacitivereactiveenergygeneratedTari󰀨1
kvar
c
h
21
