4�6�2� SECONDARY VOLTAGE
Onthisscreenthevoltagetransformersecondaryisprogrammed�
Toenterormodifythevoltagetransformersecondaryvalue,press
the keyrepeatedly,increasingthevalueoftheashingdigit�
Whentheon-screenvalueisthatdesired,pressthe keytogotothenextdigitandmodify
theothervalues�
Ifyoupressthe keyafterchangingthelastdigit,itwilljumpbacktotherstdigitsoyou
canmodifythepreviouslyprogrammedvaluesagain�
Tovalidatetheinformationandgotothenextprogrammingstep,press �
Ifthevalueenteredisgreaterthanthemaximumprogrammingvalue,thedigitsashfor2
secondsandtheprogrammedvalueisdeleted�
Maximum programming value: 999.
Minimum programming value: 0.
4�6�3� PRIMARY CURRENT
Onthisscreenthecurrenttransformerprimaryisprogrammed�
Toenterormodifythetransformerprimaryvalue,pressthe
keyrepeatedly,increasingthevalueoftheashingdigit�
Whentheon-screenvalueisthatdesired,pressthe keyto
gotothenextdigittomodifytheothervalues�
Ifyoupressthe keyafterchangingthelastdigit,itwilljumpbacktotherstdigitsoyou
canmodifythepreviouslyprogrammedvaluesagain�
Tovalidatetheinformationandgotothenextprogrammingstep,press �
Ifthevalueenteredisgreaterthanthemaximumprogrammingvalue,thedigitsashfor2
secondsandtheprogrammedvalueisdeleted�
Maximum programming value: 9999.
Minimum programming value: 0.
