4�6�15� PROGRAMMING THE DIGITAL OUTPUT ( MODEL CVM-C-xxx-RS485-C )
TheCVM-C5digitaloutputmaybeprogrammedas:
 Pulse by n kWh or kvarh (Energy):thevaluecorrespondingtotheenergyconsumed
orgeneratedmaybeprogrammed,togenerateapulse�
Alarm condition:amagnitudemaybeassociatedwiththedigitaloutput,settinga
 maximum,minimumanddelayvalueforthetripcondition�
Ifyoudonotwishtoprogramavariable,put00andvalidatewiththe key�
 Pulse programming by n kWh or kvarh
OnthisscreentheenergycodeisselectedbasedonTable 12 for
theenergyyouwantthepulseoutputtogenerate�
The keyjumpsbetweenthedi󰀨erentoptions�
Table 12: Codes for the di󰀨erent energy types.
Parameter Code
ActiveEnergyIIITari󰀨1 31
InductiveReactiveEnergyIIITari󰀨1 32
CapacitiveReactiveEnergyIIITari󰀨1 33
ApparentEnergyIIITari󰀨1 48
ActiveEnergyIIIGeneratedTari󰀨1 49
InductiveReactiveEnergyIIIGeneratedTari󰀨1 50
CapacitiveReactiveEnergyIIIGeneratedTari󰀨1 51
ApparentEnergyIIIGeneratedTari󰀨1 52
ActiveEnergyIIITari󰀨2 55
InductiveReactiveEnergyIIITari󰀨2 56
CapacitiveReactiveEnergyIIITari󰀨2 57
ApparentEnergyIIITari󰀨2 58
ActiveEnergyIIIGeneratedTari󰀨2 59
InductiveReactiveEnergyIIIGeneratedTari󰀨2 60
CapacitiveReactiveEnergyIIIGeneratedTari󰀨2 61
ApparentEnergyIIIGeneratedTari󰀨2 62
ActiveEnergyConsumed
(Regardlessofthetari󰀨selected)
99
OnceanEnergycodehasbeenselectedandvalidatedusingthe keyyoumustenterthe
kilowattsperpulse�
