4�6�4� SECONDARY CURRENT (ONLY THE MODEL CVM-C5-ITF-485)
Onthisscreenthecurrenttransformersecondaryisselected�
Usethe keytojumpbetweenthetwopossibleoptionsfor
thecurrenttransformersecondary(1Aor5A)�
Tovalidatetheinformationandgotothenextprogrammingstep,press �
Note: Ifthevoltageratiotogetherwiththeprogrammedcurrentratioexceedsthemaximum
powervaluethatcanbemeasuredbythedevice,itwillreturntotheprimaryvoltage
programmingstepwhenyoupressthe key�
Nota : To apply the change to the second current transformer is necessary to reset the computer.
4�6�5� MEASUREMENT SYSTEM
Onthisscreenthemeasurementsystemtobeusedinthe
installationisselected�
The keyjumpsbetweenthedi󰀨erentoptions
Three-phasenetworkmeasuringwitha4-wireconnection�
Three-phasenetworkmeasuringwitha3-wireconnection�
Three-phasenetworkmeasuringwitha3-wireconnectionandtransformersinan
 ARONconnection  �
Two-phasenetworkmeasuringwitha3-wireconnection�
Phase-to-phasesingle-phasenetworkmeasuringwitha2-wireconnection�
Phase-to-neutralsingle-phasenetworkmeasuringwitha2-wireconnection�
Tovalidatetheinformationandgotothenextprogrammingstep,press �
