3�- UNIT INSTALLATION
3�1�-PRIORRECOMMENDATIONS
Inordertousethedevicesafely,itiscriticalthatindividualswhohandleitfollow
thesafetymeasuresdescribedinthestandardsofthecountrywhereitisbeing
used,usethenecessarypersonalprotectiveequipment,andpayattentiontothe
variouswarningsindicatedinthisinstructionmanual�
TheCVM-C5devicemustbeinstalledbyauthorisedandqualiedsta󰀨�
The power supply plug must be disconnected and measuring systems switched o󰀨 before
handling,alteringtheconnectionsorreplacingthedevice�Itisdangeroustohandlethedevice
whileitispowered�
Also,itiscriticaltokeepthecablesinperfectconditioninordertoavoidaccidents,personal
injuryanddamagetoinstallations�
Themanufacturerofthedeviceisnotresponsibleforanydamageresultingfromfailurebythe
userorinstallertoheedthewarningsand/orrecommendationssetoutinthismanual,norfor
damageresultingfromtheuseofnon-originalproductsoraccessoriesorthosemadebyother
manufacturers�
Intheeventananomalyormalfunctionisdetectedinthedevice,refrainfromusingittotake
anymeasurements�
Inspecttheworkareabeforetakinganymeasurements�Donottakemeasurementsindanger-
ousareasorwherethereisariskofexplosion�
Disconnect the device from the power supply (device and measuring system
powersupply)beforemaintaining,repairingorhandlingthedevice'sconnections�
Pleasecontacttheafter-salesserviceifyoususpectthatthereisanoperational
faultinthedevice�
3�2�-INSTALLATION
Thedevicewillbeinstalledonapanel(92
+0�8
x92
+0�8
mmpaneldrillhole,incompliancewithDIN
43700)�Allconnectionsarelocatedinsidetheelectricpanel�
Terminals,openingcoversorremovingelementscanexposepartsthatarehaz-
ardoustothetouchwhilethedeviceispowered�Donotusethedeviceuntilitis
fullyinstalled�
Thedevicemustbeconnectedtoapowercircuitthatisprotectedwithgl(IEC269)orMtype
fuseswitharatingof0�5to2A�Itmustbettedwithacircuitbreakerorequivalentdevice,in
ordertobeabletodisconnectthedevicefromthepowersupplynetwork�
