Circutor WIBEEE Series User Manual

43
Instruction Manual
Wibeee
7�- TECHNICAL FEATURES
Note: Themetrologicalspecicationsgivenarealwayswiththerangeofadjustment.
Power supply
Rated Voltage
Wibeee-M-x , Wibeee-T-x
(1)
Wibeee-3P
(1)
85 to 265 V ~ 105... 440 V ~ (Ph-Ph)
Frequency 50 ... 60 Hz 50 ... 60 Hz
Consumption 1.5... 4.5 VA 3.5... 5.5 VA
(1)
The Wibeee-T model is powered between L1 and N. The WiBeee-3P model is powered between L2 and L3.
Voltage measurement circuit
Voltage measurement margin
Wibeee-M-x , Wibeee-T-x Wibeee-3P
85 to 265 V ~ 105... 440 V ~ (Ph-Ph)
Frequency measurement margin 50 ... 60 Hz 50 ... 60 Hz
Min� voltage measurement (Vstart) 85 V 100 V
Installation category CAT III CAT III
Current measurement circuit
Current measurement margin
Wibeee-M-x , Wibeee-T-x Wibeee-3P
1 ... 65 A 1... 65 A
Min� current measurement (Istart) 500 mA 500 mA
Installation category CAT III CAT III
Measurement accuracy
Voltage measurement 2 % + variations in range of use (at PF = 1)
Current measurement 2 % + variations in range of use
Power measurement 4 % + variations in range of use
Variations in Range of Use
Magnitude of inuence Range of inuence Typical Maximum
Temperature - 10ºC ... +45ºC - 0.3 %
Relative humidity 10% ... 90% - 0.3 %
Crosstalk (current) - 0.9 % -
External demagnetising eld (current) - 1 % -
Conductor position - 2 % 3 %
Adjust Full Scale 0.2 % 0.4 %
Distance between wire and sensor - 2.5% / 0.1 mm -
Communications
Type Wi-Fi (IEEE 802.11)
Protocol HTTP, Modbus/TCP, XML
Frequency Range 2.405 - 2.48 GHz
Encryption AES128
Monthly data consumption 300 MB
FCC(USA),IC(CANADA),ETSI(EUROPA)Certied
User interface
LED 2 LEDs
Button 1 button
Mobile application Wibeee Circutor
