Instruction Manual
Wibeee
As it is a MODBUS TCP server, the device number internally assigned to the Wibeee is 1.
Bydefault,oncecongured,theWibeee starts to send data over the internet to the CIRCUTOR
server. If you want to stop this data from being sent (for example, because the local network
does not have an Internet connection) you have to set a data refresh time of -1. This way, the
device is only waiting to handle MODBUS requests.
6.4.- MODBUS MEMORY MAP
All MODBUS map addresses are in hexadecimal format.
Table 16: Modbus memory map
Parameter Symbol Address Units Wibeee model
Phase voltage L1 Vrms1x10 0000 V x 10
Single-phase
Three-phase
Phase voltage L2 Vrms2x10 0001 V x 10 Three-phase
Phase voltage L3 Vrms3x10 0002 V x 10 Three-phase
Current L1 Irms1x10 0003 A x 10
Single-phase
Three-phase
Current L2 Irms2x10 0004 A x 10 Three-phase
Current L3 Irms3x10 0005 A x 10 Three-phase
Frequency L1 Freq1x10 0006 Hz x 10
Single-phase
Three-phase
Frequency L2 Freq2x10 0007 Hz x 10 Three-phase
Frequency L3 Freq3x10 0008 Hz x 10 Three-phase
Total Frequency FreqTx10 0009 Hz x 10
Single-phase
Three-phase
Active Power L1 Wreal1x10 000A W x 10
Single-phase
Three-phase
Active Power L2 Wreal2x10 000B W x 10 Three-phase
Active Power L3 Wreal3x10 000C W x 10 Three-phase
Total Active Power WrealTx10 000D W x 10 Three-phase
L1 Reactive Power Wreact1x10 000E Var x 10
Single-phase
Three-phase
L2 Reactive Power Wreact2x10 000F Var x 10 Three-phase
L3 Reactive Power Wreact3x10 0010 Var x 10 Three-phase
Total Reactive Power WreactTx10 0011 Var x 10 Three-phase
Apparent Power L1 Waparent1x10 0012 VA x 10
Single-phase
Three-phase
Apparent Power L2 Waparent2x10 0013 VA x 10 Three-phase
Apparent Power L3 Waparent3x10 0014 VA x 10 Three-phase
Total Apparent Power WaparentTx10 0015 VA x 10 Three-phase
Power Factor L1 PF1 x 100 0016 x 100
Single-phase
Three-phase
Power Factor L2 PF2 x 100 0017 x 100 Three-phase
Power Factor L3 PF3 x 100 0018 x 100 Three-phase
Total Power Factor TPF x 100 0019 x 100 Three-phase
Active Energy L1 Eact1 001A - 001B kWh
Single-phase
Three-phase
