Circutor WIBEEE Series - 3.3.5. Wibeee-3 P; 3.4. CONNECTION DIAGRAMS; 3.4.1. Wibeee-M-L

12
Wibeee
Instruction Manual
3�3�5�- Wibeee-3P
Table 7:List of terminals of the Wibeee-3P�
Terminals of the Wibeee-3P device
1: L1, Voltage input L1 3: L3, Voltage input L3
2: L2, Voltage input L2
1
2
3
L2
L3
Figure 7:Wibeee-3P Terminals�
3.4.- CONNECTION DIAGRAMS
3�4�1�- Wibeee-M-L
N L
Figure 8: Wibeee-M-L connection diagram�
