Table 16 (Cont�): Modbus memory map�
Parameter Symbol Address Units Wibeee model
Active Energy L2 Eact2 001C - 001D kWh Three-phase
Active Energy L3 Eact3 001E - 001F kWh Three-phase
Total Active Energy EactT 0020 - 0021 kWh Three-phase
Inductive Reactive Energy L1 EreactL1 0022 - 0023 kVarh
Single-phase
Three-phase
Inductive Reactive Energy L2 EreactL2 0024 - 0025 kVarh Three-phase
Inductive Reactive Energy L3 EreactL3 0026 - 0027 kVarh Three-phase
Total Inductive Reactive Energy EreactLT 0028 - 0029 kVarh Three-phase
Capacitive Reactive Energy L1 EreactC1 002A - 002B kVarh
Single-phase
Three-phase
Capacitive Reactive Energy L2 EreactC2 002C - 002D kVarh Three-phase
Capacitive Reactive Energy L3 EreactC3 002E - 002F kVarh Three-phase
Total Capacitive Reactive Energy EreactCT 0030 - 0031 kVarh Three-phase
Function 05 is used to delete energy meters.
Table 17:Modbus memory map: Deleting parameters
Deleting parameters Address Value to be sent
Deleting energy meters 0000 0xFF00
