Page #44 background imageLoading...
Page #44 background image
5-4
Cisco 10000 Series Router Troubleshooting Guide
OL-0439-02
Chapter 5 Cisco 10000 Series Router Alarms and Error Messages
OC-12 POS Line Card Alarms and Error Messages
OC-12 POS Line Card Error Messages
Table 5-3 describes hardware-related error messages that the OC-12 POS line card can report. It also
defines the problem causing the error message and suggests a corrective action.
BER_SF
Signal Fail condition
Minor
BER_SF and BER_SD alarms
result in APS cutovers.
In both cases, test the quality of
the cables and connections.
BER_SD
Signal degrade condition
Minor
For more information on signal
fail (BER_SF) and signal
degrade (BER_SD) alarms, refer
to the APS chapter in the
Cisco 10000 Series Router
Broadband Aggregation,
Leased-Line, and MPLS
Configuration Guide. These
BER thresholds can be specified
by the user.
Table 5-2 BER Alarms (continued)
Alarm Type and Severity Alarm Symptoms Recommendation
Table 5-3 OC-12 POS Hardware-Related Error Messages
Error Message Cause of Error Message Corrective Action
LC_ERROR: Slot(x/0)
1oc12pos-1 DataPathControl:
Hardware Fatal Error
These alarm messages announce
unrecoverable OC-12 POS line
card hardware failures.
In all cases, follow this
procedure:
1. Replace the OC-12 POS line
card.
2. Call the Cisco TAC.
LC_ERROR: Slot(x/0)
1oc12pos-1 FromPRE: Hardware
Fatal Error
LC_ERROR: Slot(x/0)
1oc12pos-1 ToPRE: Hardware
Fatal Error
LC_ERROR: Slot(x/0)
1oc12pos-1 Port0: Transmit
Clock Hardware Fatal Error
LC_ERROR: Slot(x/0)
1oc12pos-1 ToPRE/FromPRE:
Hardware Download Fatal
Error
LC_ERROR: Slot(x/0)
1oc12pos-1 FromPRE: Hardware
Configuration Fatal Error
LC_ERROR: Slot(x/0)
1oc12pos-1 ToPRE: Hardware
Configuration Fatal Error
