5-2
Cisco 12000 Series Router SIP and SPA Hardware Installation Guide
Release 12.0(32)SY1, OL-8831-01, Rev. G6, July 19, 2007
Chapter 5 Installing and Removing a Shared Port Adapter
SPA Installation and Removal
SPA Installation and Removal
This section provides step-by-step instructions for removing and installing a SPA in an SIP.
Warning
When performing the following procedures, wear a grounding wrist strap to avoid ESD damage to the
SPA. Some platforms have an ESD connector for attaching the wrist strap. Do not directly touch the
midplane or backplane with your hand or any metal tool, or you could shock yourself.
Installing a SPA in a SIP
To install a SPA in a SIP, refer to Figure 5-2 and do the following:
Step 1 To insert the SPA in the SIP, locate the guide rails inside the SIP that hold the SPA in place. They are at
the top left and top right of the SPA slot and are recessed about an inch, as shown in C of Figure 5-2.
Step 2 Carefully slide the SPA all the way in the SIP until the SPA is firmly seated in the SPA interface connector.
When fully seated, the SPA might be slightly behind the SIP faceplate.
Step 3 After the SPA is properly seated, turn the SPA lock to its locked and horizontal position, as shown in A
of Figure 5-2.
Removing a SPA from a SIP
To remove a SPA from a SIP, refer to Figure 5-2 and do the following:
Step 1 If attached, remove any cables from the SPA.
Step 2 To remove the SPA from the SIP, turn the SPA lock from its locked and horizontal position shown in A
of Figure 5-2 to its unlocked and vertical position shown in B of Figure 5-2.
Step 3 Grasp the handle of the SPA and pull the SPA from the SIP. (Ensure that you have already disconnected
the cables from the SPA before removing the SPA from the SIP).
