2-15
Cisco 12000 Series Router SIP and SPA Hardware Installation Guide
Release 12.0(32)SY1, OL-8831-01, Rev. G6, July 19, 2007
Chapter 2 Overview: Cisco 12000 Series Router Shared Port Adapters
2-Port Gigabit Ethernet SPA Overview
Figure 2-11 XFP Illustration
XFP Port Cabling Specifications
2-Port Gigabit Ethernet SPA Overview
The following sections describe the 2-Port Gigabit Ethernet SPA:
2-Port Gigabit Ethernet SPA LEDs, page 2-16
SFP Module Cabling and Connection Equipment, page 2-18
129499
Table 2-12 XFP Port Cabling Specifications
XFP Wavelength Fiber Type
XFP-10GLR-OC192SR 1310 nm SMF
XFP-10GER-OC192IR 1550 nm SMF
XFP-10GZR-OC192LR 1550 nm SMF
