1-6
Cisco 12000 Series Router SIP and SPA Hardware Installation Guide
Release 12.0(32)SY1, OL-8831-01, Rev. G6, July 19, 2007
Chapter 1 Overview: Cisco 12000 Series Router SPA Interface Processors
Cisco 12000 SIP-400 Overview
Cisco 12000 SIP-400 Physical Specifications
The Cisco 12000 SIP-400 physical specifications are shown in the following table.
SPA Slot Numbering on the Cisco 12000 SIP-400
The Cisco 12000 SIP-400 accepts 4 single-width, single-height SPAs.
Figure 1-3 shows a Cisco 12000 SIP-400 with 4 SPAs installed. The top leftmost SPA slot is subslot 0;
the top rightmost SPA slot is subslot 1; the bottom leftmost SPA slot is subslot 2; the bottom rightmost
SPA slot is subslot 3.
Figure 1-3 Cisco 12000 SIP-400 with SPAs Installed
Table 1-4 Cisco 12000 SIP-400 LED
LED Label Color State Meaning
Status Yellow On IOS is loaded and SIP is ready to be enabled.
Green On SIP is active.
Table 1-5 Cisco 12000 SIP-400 Physical Specifications
Description Specifications
Physical dimensions Occupies one line card slot on a Cisco 12000 Series Router
Shipping weight 10 kg
Operating temperature 32 to 104°F (0 to 40°C)
Relative humidity 10 to 90 percent, noncondensing
Storage temperature –4 to 149°F (–20 to 65°C)
122066
12000-SIP-400
1
3
2
0
STATUS
C/A
TX
RX
1
STATUS
SPA-4XT3/E3
0
A/L
C/A
TX
RX
A/L
C
/A
TX
RX
2
A/L
C/A
TX
RX
3
A/L
C/A
TX
RX
1
STATUS
SPA-4XT3/E3
0
A/L
C/A
TX
RX
A/L
C/A
TX
RX
2
A/L
C/A
TX
RX
3
A/L
C/A
TX
RX
1
STATUS
SPA-4XT3/E3
0
A/L
C/A
TX
RX
A/L
C/A
TX
RX
2
A/L
C/A
TX
R
X
3
A/L
C/A
TX
RX
1
STATUS
SPA-4XT3/E3
0
A/L
C/A
TX
RX
A/L
C/A
TX
RX
2
A/L
C/A
TX
R
X
3
A/L
1
2
3
4
