1-18
Cisco 12000 Series Router SIP and SPA Hardware Installation Guide
Release 12.0(32)SY1, OL-8831-01, Rev. G6, July 19, 2007
Chapter 1 Overview: Cisco 12000 Series Router SPA Interface Processors
Cisco 12000 SIP-601 Overview
Cisco 12000 SIP-601 Overview
The following sections describe the Cisco 12000 SIP-601:
Cisco 12000 SIP-601 Board Components, page 1-18
Cisco 12000 SIP-601 LEDs, page 1-18
Cisco 12000 SIP-601 Physical Specifications, page 1-19
SPA Subslot Numbering on the Cisco 12000 SIP-601, page 1-20
SPA Interface Addresses on the Cisco 12000 SIP-601, page 1-20
Cisco 12000 SIP-601 Board Components
The main Cisco 12000 SIP-601 board components are shown in Figure 1-17.
Figure 1-17 Cisco 12000 SIP-601 Board—Rear View
Cisco 12000 SIP-601 LEDs
The Cisco 12000 SIP-601 supports 4 single-height SPAs (the aggregate throughput should not exceed 2
full-rate SPAs); 2 double-height SPAs; 1 dual-width, double-height SPA, or a combination of
single-height and double-height SPAs.
Table 1-15 Slot and Port Locations for the 1-Port 10-Gigabit Ethernet SPA
Call Out Number Description
1Slot 3
2 Subslot 0, Port 3/0/0
3 Subslot 1, Ports 3/1/0 to 3/1/9
1 SPA enclosure 2 Backplane connector
122074
1
2
