Cisco 12000 SIP-401 Overview
Cisco 12000 SIP-401 Overview
The following sections describe the Cisco 12000 SIP-401:
• Cisco 12000 SIP-401 Board Components, page 1-11
• Cisco 12000 SIP-401 LEDs, page 1-11
• Cisco 12000 SIP-401 Physical Specifications, page 1-12
• SPA Slot Numbering on the Cisco 12000 SIP-401, page 1-12
• SPA Interface Addresses on the Cisco 12000 SIP-401, page 1-13
Cisco 12000 SIP-401 Board Components
The main Cisco 12000 SIP-501 board components are shown in Figure 1-9.
Figure 1-9 Cisco 12000 SIP-401 Board—Rear View
Cisco 12000 SIP-401 LEDs
The Cisco 12000 SIP-401 has two LEDs, as shown in Figure 1-10.
Table 1-9 Slot and Port Locations for the 1-Port 10-Gigabit Ethernet SPA
Call Out Number Description
1Slot 3
2 Subslot 0, Port 3/0/0
3 Subslot 1, Ports 3/1/0 to 3/1/9
1 SPA enclosure 2 Backplane connector
122074
1
2
