Chapter 6 Clustering Switches

Planning a Switch Cluster

Figure 6-7 Discovery of Newly Installed Switches in the Same Management VLAN

Figure 6-8 Discovery of Newly Installed Switches in Different Management VLANs

APAP

Command switch

Catalyst 3500 XL

switch

Catalyst 2950

switch

VLAN 16

New (out-of-box)

Catalyst 2900 LRE XL

switch

New (out-of-box)

Catalyst 2950

switch

65581

(Management

VLAN 16)

(Management

VLAN 16)

Command switch

New (out-of-box)

Catalyst 2950

switch

Catalyst 2950

switch

VLAN 9

VLAN 16

New (out-of-box)

Catalyst 3550

switch

Catalyst 3500 XL

switch

74050

(Management

VLAN 9)

(Management

VLAN 16)
