16-6
Catalyst 2950 Desktop Switch Software Configuration Guide
78-14982-01
Chapter 16 Configuring Voice VLAN
Displaying Voice VLAN
Configuring the IP Phone to Trust the CoS Priority of Incoming Data Frames
You can connect a PC or other data device to a Cisco 7960 IP Phone port. The PC can generate packets
with an assigned CoS value. You can configure the switch to trust the priority of frames arriving on the
IP phone port from connected devices.
Beginning in privileged EXEC mode, follow these steps to trust the CoS priority received from the
nonvoice port on the Cisco 7960 IP Phone:
To return the port to its default setting, use the no switchport voice vlan interface configuration
command or the switchport priority extend none interface configuration command.
Displaying Voice VLAN
To display voice VLAN for an interface, use the show interfaces interface-id switchport privileged
EXEC command.
For detailed information about the fields in the display, refer to the command reference for this release.
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
interface interface-id Enter interface configuration mode, and specify the interface connected to
the IP phone.
Step 3
switchport priority extend trust Set the IP phone access port to trust the priority received from the PC or the
attached device.
Step 4
end Return to privileged EXEC mode.
Step 5
show interfaces interface-id
switchport
Verify your entries.
Step 6
copy running-config startup-config (Optional) Save your entries in the configuration file.
