Catalyst 2950 Desktop Switch Software Configuration Guide
78-14982-01
Chapter 11 Configuring STP
Configuring Spanning-Tree Features
To return the switch to its default setting, use the no spanning-tree vlan vlan-id forward-time global
configuration command.
Configuring the Maximum-Aging Time for a VLAN
Beginning in privileged EXEC mode, follow these steps to configure the maximum-aging time for a
VLAN:
To return the switch to its default setting, use the no spanning-tree vlan vlan-id max-age global
configuration command.
Configuring STP for Use in a Cascaded Stack
STP uses default values that can be reduced when configuring your switch in cascaded configurations.
If a root switch is part of a cluster that is one switch from a cascaded stack, you can customize spanning
tree to reconverge more quickly after a switch failure. Figure 11-4 shows switches in three cascaded
stacks that use the GigaStack GBIC. Table 11-4 shows the default STP settings and those that are
acceptable for these configurations.
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
spanning-tree vlan vlan-id max-age seconds Configure the maximum-aging time of a VLAN. The
maximum-aging time is the number of seconds a switch waits
without receiving spanning-tree configuration messages before
attempting a reconfiguration.
• For vlan-id, the range is 1 to 4094 when the EI is installed
and 1 to 1005 when the SI is installed. Do not enter leading
zeros.
• For seconds, the range is 6 to 40; the default is 20.
Step 3
end Return to privileged EXEC mode.
Step 4
show spanning-tree vlan vlan-id Verify your entries.
Step 5
copy running-config startup-config (Optional) Save your entries in the configuration file.
Table 11-4 Default and Acceptable STP Parameter Settings (in seconds)
STP Parameter STP Default Acceptable for Option 1 Acceptable for Option 2 Acceptable for Option 3
Hello Time 2 1 1 1
Max Age 20 6 10 6
Forwarding Delay 15 4 7 4
