Chapter 3 Getting Started with CMS
Front Panel View
To select or change a mode, click the Mode button until the desired mode LED is green.
VLAN Membership Modes
Ports in the Front Panel view are outlined by colors (see Table 3-6) when you click Highlight VLAN
Port Membership Modes on the Configure VLANs tab on the VLAN window
(VLAN > VLAN > Configure VLANs). The colors show the VLAN membership mode of each port.
The VLAN membership mode determines the kind of traffic the port carries and the number of VLANs
it can belong to. For more information about these modes, see the “VLAN Port Membership Modes”
section on page 14-3.
Note This feature is not supported on the Catalyst 1900 and Catalyst 2820 switches.
Table 3-4 Port Modes
Mode LED Description
STAT Link status of the ports or the Ethernet link status on the remote customer premises equipment
(CPE) device. This is the default mode except for the Catalyst 2950 LRE switches.
DUPLX Duplex setting on the ports. The default setting on the 10/100 ports is auto. The default setting
on the 10/100/1000 ports is full.
SPEED Speed setting on the ports. The default setting on the 10/100 and 10/100/1000 ports is auto.
Table 3-5 Port LEDs
Port Mode Port LED Color Description
STAT Cyan (off) No link.
Green Link present.
Amber Link fault. Error frames can affect connectivity, and errors such as excessive
collisions, CRC errors, and alignment and jabber errors are monitored for a link-fault
indication.
Port is not forwarding. Port was disabled by management, by an address violation,
or by Spanning Tree Protocol (STP).
Note After a port is reconfigured, the port LED can remain amber for up to
30 seconds as STP checks the switch for possible loops.
Brown No link and port is administratively shut down.
DUPLX Cyan (off) Port is operating in half-duplex mode.
Green Port is operating in full-duplex mode.
SPEED Cyan (off) Port is operating at 10 Mbps (10/100 ports) or no link (10/100/1000 ports and GBIC
module ports).
Green Port is operating at 100 Mbps (10/100 ports) or 1000 Mbps (GBIC module ports).
Blinking green Port is operating at 1000 Mbps (10/100/1000 ports).
