3-24
Catalyst 2950 Desktop Switch Software Configuration Guide
78-14982-01
Chapter 3 Getting Started with CMS
Menus and Toolbar
Table 3-17 Device Popup Menu of a Command-Switch Icon
Popup Menu Option Task
Collapse cluster View the neighborhood outside a specific cluster.
Host Name
1
1. Not available in read-only mode. For more information about the read-only and read-write access modes, see the “Access
Modes in CMS” section on page 3-31.
Change the host name of a switch.
Bandwidth Graphs Display graphs that plot the total bandwidth in use by the switch.
Properties Display information about the device.
Table 3-18 Device Popup Menu of a Member or Standby Command-Switch Icon
Popup Menu Option Task
Remove from Cluster
1
1. Available only from a cluster-management session.
Remove a member from the cluster.
Host Name
1
Change the host name of a switch.
Device Manager
2
2. Available from a cluster member switch but not from the command switch.
Launch Device Manager for a switch.
Bandwidth Graphs Display graphs that plot the total bandwidth in use by the switch.
Properties Display information about the device.
Table 3-19 Device Popup Menu of a Candidate-Switch Icon (When the Candidate Switch Has an
IPAddress)
Popup Menu Option Task
Add to Cluster
1
1. Not available in read-only mode. For more information about the read-only and read-write access modes, see the “Access
Modes in CMS” section on page 3-31.
Add a candidate to a cluster.
Device Manager
2
2. Available from a cluster member switch but not from the command switch.
Launch Device Manager for a switch.
Properties Display information about the device.
Table 3-20 Device Popup Menu of a Candidate-Switch Icon (When the Candidate Switch Does Not
Have an IP Address)
Popup Menu Option Task
Add to Cluster
1
1. Not available in read-only mode. For more information about the read-only and read-write access modes, see the “Access
Modes in CMS” section on page 3-31.
Add a candidate to a cluster.
Properties Display information about the device.
