Chapter 6 Install and Upgrade Internal Modules and FRUs
Replace a Fan Tray
Figure 6-45 Cisco 4331 ISR Fan Tray
364660
2
2
2
5
5
2
4
1
3
1 Chassis cover 3 Fan tray
2 Cover screws (4) 4 Spring-lock
5 Cover screws on the side of the chassis (2)
