Cisco 4431 ISR User Manual

iii
Hardware Installation Guide for Cisco 4000 Series Integrated Services Routers
OL-32185-02
CONTENTS
Preface xi
Objectives xi
Audience xi
Organization xii
Conventions xiii
Related Documentation xix
Searching for Cisco Documents xx
Obtaining Documentation and Submitting a Service Request xx
CHAPTER 1 Overview of Cisco 4000 Series ISRs 1-1
About Cisco 4000 Series ISRs 1-1
Cisco 4451-X ISR 1-2
Cisco 4431 ISR 1-3
Cisco 4351 ISR 1-3
Cisco 4331 ISR 1-4
Cisco 4321 ISR 1-5
Cisco 4221 ISR 1-5
Safety Warnings 1-6
Safety Warnings for Finland, Norway, and Sweden 1-6
Chassis Views 1-6
Cisco 4451 ISR Chassis 1-7
Platform Summary 1-10
Cisco 4431 ISR Chassis 1-10
Platform Summary 1-13
Cisco 4351 ISR Chassis 1-14
Platform Summary 1-16
Cisco 4331 ISR Chassis 1-17
Platform Summary 1-18
Cisco 4321 ISR Chassis 1-19
Platform Summary 1-20
Cisco 4221 ISR Chassis 1-21
Platform Summary 1-23
Hardware and Module Configuration 1-24

Cisco 4431 ISR Specifications

General

Total onboard WAN or LAN 10/100/1000 ports	4
RJ-45-based ports	4
SFP-based ports	2
NIM slots	2
Enhanced service-module slots	1
Rack height	1 RU
Redundant power supply	Optional
Memory	4 GB
Flash Memory	4 GB
USB Ports	2
Console Port	1 x RJ-45
Auxiliary Port	1 x RJ-45
Power Supply	AC 100-240V
Operating Temperature	0 to 40°C
Storage Temperature	-20 to 65°C
Humidity	5% to 85% noncondensing
Dimensions (H x W x D)	44.5 x 438.15 x 438.15 mm
Weight	7.5 kg (16.5 lb)
