Cisco 4431 ISR User Manual

6-70
Hardware Installation Guide for Cisco 4000 Series Integrated Services Routers
OL-32185-02
Chapter 6 Install and Upgrade Internal Modules and FRUs
Install and Remove an SSD mSATA Storage Device
Step 6 Replace the chassis cover. See “Remove and Replace the Chassis Cover” section on page 6-4.
Remove the SSD mSATA Storage Device
To remove the SSD mSATA storage device:
Step 1 Read the “Safety Warnings” section on page 6-2 and disconnect the power supply before you replace any
module.
Step 2 Remove the chassis cover. For instructions on removing the chassis cover, see “Remove and Replace the
Chassis Cover” section on page 6-4.
Step 3 Unscrew the screws that attach the SSD mSATA storage device to the chassis. See Figure 6-48.
Step 4 The card should popup once the screws are removed.
Step 5 Install a new SSD mSATA memory device if needed. See Install the SSD mSATA Storage Device,
page 6-69.
Step 6 Replace the chassis cover. See “Remove and Replace the Chassis Cover” section on page 6-4.
1 Supplied screw 2 Supplied screw
3 Flash memory card 4 SSD mSATA storage device
5 Flash memory card connector 6 SSD mSATA connector

Cisco 4431 ISR Specifications

General

Total onboard WAN or LAN 10/100/1000 ports	4
RJ-45-based ports	4
SFP-based ports	2
NIM slots	2
Enhanced service-module slots	1
Rack height	1 RU
Redundant power supply	Optional
Memory	4 GB
Flash Memory	4 GB
USB Ports	2
Console Port	1 x RJ-45
Auxiliary Port	1 x RJ-45
Power Supply	AC 100-240V
Operating Temperature	0 to 40°C
Storage Temperature	-20 to 65°C
Humidity	5% to 85% noncondensing
Dimensions (H x W x D)	44.5 x 438.15 x 438.15 mm
Weight	7.5 kg (16.5 lb)
