Hardware Installation Guide for the Cisco 4000 Series Integrated Services Router
OL-32185-02
Chapter 1 Overview of Cisco 4000 Series ISRs
Specifications
Specifications
The following table provides Cisco 4451 ISR specifications.
Table 1-7 Cisco 4451 ISR Router Specifications
Description Specification
Physical
Dimensions (H x W x D) 3.5 x 17.25 x 18.7 in. (88.9 x 438.2 x 474.9 mm)
2 RU height
Weight with AC PS (w/o modules) 28.5 lbs (12.92 kg)
Weight with dual AC-PoE PS (w/o modules) 30.0 lbs (13.6 kg)
Weight with dual AC + PoE Adaptor (w/o
modules)
38.0-40.0 lbs (17.23-18.14 kg)
Power
AC input power
• Input voltage 100 to 240 VAC, autoranging
• Frequency 47 to 63 Hz
• Input current 5.3 A
• Input current with PoE Power Adaptor 7.4 A
• Surge current 60 A peak and less than 12 Arms per half cycle
Power consumption 75 to 320 W, 256 to 1092 BTU/hr (configuration
dependent)
• With AC-PoE 80 to 750 W, 273 to 2560 BTU/hr (configuration
dependent)
Ports
Console port One RJ-45 connector and one mini USB Type B,
USB 2.0 compliant
Auxiliary port RJ-45 connector
USB ports Two USB Type A, USB 2.0 compliant, 2.5 W (500
mA) max
1
1. 480 Mb/s individually; bandwidth is shared when both are used.
The following table provides Cisco 4431 ISR specifications.
10/100/1000 Gigabit Ethernet Four RJ-45 connectors (GE0/0/0, GE0/0/1,
GE0/0/2, GE0/0/3), auto-MDIX
SFP After an SFP module is installed, the adjacent
RJ-45 GE connector is disabled.

Cisco 4431 ISR Specifications

General

Total onboard WAN or LAN 10/100/1000 ports	4
RJ-45-based ports	4
SFP-based ports	2
NIM slots	2
Enhanced service-module slots	1
Rack height	1 RU
Redundant power supply	Optional
Memory	4 GB
Flash Memory	4 GB
USB Ports	2
Console Port	1 x RJ-45
Auxiliary Port	1 x RJ-45
Power Supply	AC 100-240V
Operating Temperature	0 to 40°C
Storage Temperature	-20 to 65°C
Humidity	5% to 85% noncondensing
Dimensions (H x W x D)	44.5 x 438.15 x 438.15 mm
Weight	7.5 kg (16.5 lb)
