Platform Summary
Figure 1-16 shows the internal view of the Cisco 4431 ISR with parts and module locations.
Figure 1-16 Platform Summary of Cisco 4331 ISR Chassis
1 Double-wide NIM 2 NIMs
3 Removable module slot divider 4 SM-X slot
5 Ground connection
1 DIMMs 2 CPU
3 ISC slot 4 SM-X slot
5 NIM slot
