Appendix E Installing the Wall Mount for the Cisco Unified IP Phone 6901 and 6911
Installing a Wall Mount for the Cisco Unified IP Phone 6901
Step 2 Plug the RJ45 connector into the wall mount phone jack (Figure E-4).
Figure E-4 RJ45 Connector in the Wall Mount Jack
1 Network Port on the Phone 3 Wall Mount Plate
2 RJ45 Connector 4 Network Port on the Wall Mount Plate
253656
2
1
4
3
