Appendix E Installing the Wall Mount for the Cisco Unified IP Phone 6901 and 6911
Installing a Wall Mount for the Cisco Unified IP Phone 6901
Step 3 Slip the mounting holes on the base of the wall mount plate and over the wall mount pins (Figure E-5).
Figure E-5 Mounting Holes
1 Mounting Hole on the Phone
2 Wall Mount Pin on the Wall Mount Plate
253657
1
2
