Chapter 3 Setting Up the Cisco Unified IP Phone
Installing the Cisco Unified IP Phone
Figure 3-1 Cisco Unified IP Phone 6901 Cable Connections
4
5
6
1
2
3
195792
1
Slot for Ethernet cable
4
Network port (10/100 SW) connection
IEEE 802.3af power enabled
2
Handset connection
5
DC adaptor port (DC48V)
3
Slot for handset cable
6
Slot for DC adaptor cable
