CHAPTER

1-1

Cisco Aironet 1200 Series Access Point Software Configuration Guide

OL-2159-01

Overview

Cisco Aironet access points are wireless LAN transceivers that serve as the center

point of a stand-alone wireless network or as the connection point between

wireless and wired networks. In large installations, wireless users within radio

range of an access point can roam throughout a facility while maintaining

seamless, uninterrupted access to the network.

The access point uses a browser-based management system, but you can also

configure the access point using a terminal emulator, a Telnet session, or Simple

Network Management Protocol (SNMP).

This chapter provides information on the following topics:

• Key Features, page 1-2

• Management Options, page 1-2

• Network Configuration Examples, page 1-3
