Cisco Aironet 1200 Series - Appendix A Channels, Power Levels, and Antenna Gains

272 pages

To Next Page

To Previous Page

A-1

Cisco Aironet 1200 Series Access Point Software Configuration Guide

OL-2159-01

APPENDIX

Channels, Power Levels, and Antenna

Gains

This appendix lists the channels supported by the world's regulatory domains as

well as the maximum power levels and antenna gains allowed per domain.

This appendix covers these topics:

• Channels, page A-2

• Maximum Power Levels and Antenna Gains, page A-3
