Cisco Aironet 1200 Series

To Next Page

To Previous Page

Chapter 3 Configuration

Basic Settings

3-6

Cisco Aironet 1200 Series Access Point Software Configuration Guide

OL-2159-01

• Repeater Access Point—An access point that transfers data between a client

and another access point or repeater. Use this setting for access points not

connected to the wired LAN. Figure 3-3 shows an access point operating as a

repeater in a network.

Note Non-Cisco client devices might have difficulty communicating with

repeater access points.

Figure 3-3 Repeater Access Point

Access Point

(Root Unit)

Access Point

(Repeater)

66000

Wired LAN
