Cisco ASR 1001-X Router Hardware Installation Guide
OL-32376-02
Chapter 6 Cisco ASR 1001-X Router License Verification
Per Port Counted License (10-GE Interfaces)
• An End-User License Agreement (EULA) will be displayed for each port if there is no permanent
license present to support these ports.
• The image carries 2-count 10-GE port EvalRTU (Evaluation) licenses. If the EvalRTU license
expires, it becomes a Right-To-Use (RTU) license.
• The no shut command on a 10-GE interface requests one count of the license, and the In-use count
increases by 1.
• The shut command on a 10-GE interface releases one count of the license, and the In-use count
decreases by 1.
The following EvalRTU license example displays the EvalRTU licenses used on the 10-GE ports. A
Permanent license would work similarly:
StoreIndex: 13 Feature: interface_10g Version: 1.0
License Type: EvalRightToUse
License State: Inactive
Evaluation total period: 8 weeks 4 days
Evaluation period left: 8 weeks 1 day
Period used: 2 days 8 hours
Lock type: Non Node locked
Vendor info: <UDI><PID>NOTLOCKED</PID><SN>NOTLOCKED</SN></UDI><T>RTU</T>
License Addition: Additive
License Generation version: 0x8200000
License Count: 0/0 (In-use/Violation)
License Priority: Low
StoreIndex: 13 Feature: interface_10g Version: 1.0
License Type: EvalRightToUse
License State: Active, In Use
Evaluation total period: 8 weeks 4 days
Evaluation period left: 2 weeks 6 days
Period used: 5 weeks 4 days
Transition date: Jun 09 2014 05:14:47
Lock type: Non Node locked
Vendor info: <UDI><PID>NOTLOCKED</PID><SN>NOTLOCKED</SN></UDI><T>RTU</T>
License Addition: Additive
License Generation version: 0x8200000
License Count: 2/0 (In-use/Violation)
License Priority: Low
Table 6-5 show license all Command Output Description
Field Name Description
License Count: 0/0 (In-use/Violation)
No 10-GE ports in use for the evaluation license.
License Count: 2/0 (In-use/Violation)
Two 10-GE ports in use for the evaluation license
(a EULA was accepted for each prior to use).

Cisco ASR 1001-X Specifications

General

Product color	Gray
Rack capacity	1U
Rack mounting	Yes
Networking standards	-
Ethernet LAN (RJ-45) ports	6
Installed SFP modules quantity	2
Flash memory	1024 MB
Internal memory	8192 MB
Processor cores	4
AC input voltage	85 - 264 V
Power source type	AC
Power consumption (typical)	250 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %
Security algorithms	AES

Weight and Dimensions

Depth	461.5 mm
Width	439.42 mm
Height	43.43 mm
Weight	10590 g
